Features
- Detects opens, shorts, miss wires and split pairs on twisted pair cabling.
- Measures length.
- Low battery detector.
- Auto backlit.
- Auto power off.
Downloads
Technical Specifications
| Items | Descriptions |
|---|---|
| Cable type tested | UTP, STP |
| Cable category | RJ-45, F-CAT5, CAT6 |
| Wire-map test | Detects opens, shorts, miswires, split pairs |
| Display | 58mm(L} x45mm(W) Monochrome LCD with backlit. |
| Battery | 1.5Vx6 batteries (LR03 SIZE AAA 1.SV) |
| Battery Life | Approximately testing 200 times. |
| Shutoff Rate Power | 1uA. |
| Operate Maximum Power | 20mA |
| Dimension | 156x73x35mm(LxWxH) |
| Weight | About 170g |
| Accessories | User's manualx1, 1.5V AAA battery x6, CATS STP Cable x1,remote 10(1) x1. |
